Parameter 参数 |
Value 价值 |
|
Size 大小 |
32cm L x 12cm W x 10 cm H |
|
Weight 重量 |
typically <4 kg |
|
F/number F/ 号码 |
F/3 |
|
Spectral range (free of second order effects)
光谱范围（无二阶效应） |
90-95% of an octave in the 350 nm to 2500 nm range |
|
Spot diameter 直径 |
19 µm @ 1000 nm in 25.4 x 9 mm2 area |
|
Spectral resolution (0.024 mm wide pixels)
光谱分辨率（0.024毫米宽像素） |
0.5 nm @ 400 nm and 2 nm @ 2000 nm |
|
Linear dispersion 线性色散 |
90%-95% of an octave per inch |
|
Maximum detector size 最大规模探测器 |
25.4 x 12.7 mm |
|
Dynamic range of a single 0.024 by 0.024 mm2 pixel
动态范围由单一的0.024到0.024毫米2像素 |
> 3,000 (depends on detector used) |
